little black box!!!

[rideforever13]

theres a little black box dangling with wires runnin to it under the drivers dash that clicks on and off when i turn the jeep off. and now my battery is dead! what is that box!!!????



[dslywalker]

If its hooked to the wipers it could be the wiper relay or signal flasher.Can you trace the wires back to a place of origin.Is it a plugin box that you could pull it out and see if your battery stays up or it keeps something else from functioning.There's some articles in the DOC sections here that could help you.
Maybe someone with a 84 might know also.My 83 didn't have anything like what your describing.



[54cj3b]

If it was in a plane I'd say it was the voice recorder lol

It could be the buzzer letting you know keys still in ignition



[Cheepjeep85]

if i had my guess things like that are usually whats left of a cheap <-BAD WORD-> security system. does it look modern? (newer lookin plastic, bright shiny wires) if so i'd say thats what it is. get you a jeep wiring diagram and see if you can trace what its hooked up to, that'll tell you what it is.



[CJim7]

My '84 has nothing like that.

Maybe it's a government tracking device



[CJ]

A picture would sure help... Can you tell us what is connected to?



[rideforever13]

ya i dont know where they go, ill look tomorrow and post up a picture
thanks for the help



[rideforever13]

heres the box and, the wires are a cluster f***, but it says
SF-3728007
UTA-1224
hope its not some kinda tracking device from an old girlfriend !!!



[rideforever13]

o and on the other side it has a white sticker that says "do not break seal"
and of course some dummy before me broke the seal



[CJ]

Intermittent wiper module.

SF-3728007 - Google Search

Discontinued , NOS AMC Jeep intermittent wiper module - eBay (item 200562159574 end time Jan-15-11 13:17:42 PST)



[rideforever13]

awesome! soooo if i cut it and take it out will my wipers still work ?



[CJ]

I highly doubt it. Can't be sure without a wiring diagram. I would look for the bracket that it mounts in and reattach it.



[CJim7]

You have intermittent wipers on your '84. Im jealous



[dslywalker]

Read this thread
intermittent wiper mod. - JeepForum.com



[Cheepjeep85]

good you found out what it is, definately not what i was expecting to find on an 84.



[CJ]

Read this thread
intermittent wiper mod. - JeepForum.com

Read that thread, heck, if it works - why not just leave it alone?



[Cheepjeep85]

really most of us dream (well thats a bit of exaggeration) of intermittent wipers.



[dslywalker]

Read that thread, heck, if it works - why not just leave it alone?

Its draining his battery.I had it on mine and it did the same thing.They put it in a place where water can get if the top is down.If it was like mine it sets in a compartment screwed to the dash where water can settle.



[CJ]

Its draining his battery.I had it on mine and it did the same thing.They put it in a place where water can get if the top is down.If it was like mine it sets in a compartment screwed to the dash where water can settle.

So it fills when wet? As you said - flip it so the wires are down.

Good Idea!



[dslywalker]

So it fills when wet? As you said - flip it so the wires are down.

Good Idea!

By that time its pretty much shot.It was just one of AMC's bad ideas.
